DJI Mic (2 TX + 1 RX + Charging Case)

DJI Mic: The Ultimate Wireless Microphone System

DJI Mic is a compact and versatile wireless microphone system designed for content creators, vloggers, and filmmakers. With its powerful performance, exceptional audio quality, and intuitive operation, DJI Mic offers a seamless solution for capturing clear and crisp sound in various environments.

Key Features:

• Dual-Channel Transmission: The system includes two transmitters, allowing you to record audio from two sources simultaneously. This is ideal for interviews, podcasts, or vlogging with a guest.
• Long-Range Transmission: DJI Mic boasts a stable and reliable transmission range of up to 250 meters, ensuring clear audio even in challenging conditions.
• High-Quality Audio: Equipped with high-sensitivity microphones, DJI Mic captures detailed and natural sound. The system also features advanced noise reduction technology to minimize background interference.
• Compact and Portable: The transmitters and receiver are incredibly small and lightweight, making them easy to carry and use on the go. The included charging case provides convenient power management and protection.
• Intuitive Operation: DJI Mic is designed with user-friendliness in mind. The simple interface and easy setup process allow you to start recording high-quality audio in no time.

Applications:

• Vlogging and Content Creation: Capture clear and professional audio for your videos, podcasts, and livestreams.
• Interviews and Documentaries: Conduct high-quality interviews and record natural dialogue for your documentary projects.
• Filmmaking and Production: Enhance your filmmaking projects with crystal-clear audio for dialogue, sound effects, and ambient sounds.

Experience the power of DJI Mic and elevate your audio recordings to new heights.

Take a Closer Look

All-In-One Storage, Ready to Use

The transmitters and receiver are linked, charged, and securely stored in the charging case, making it easy to carry and use instantly.

250m (820 ft.) Range Up to 250m (820 ft.) audio transmission range is supported in open, unobstructed environments without interference. Cable-free, hassle-free.	15-Hour Battery Enjoy 5.5 hours of battery life from the transmitters, and up to 15 hours with the charging case. Spend less time worrying about battery level.

Magnetic Attachment The transmitter has a convenient back clip and magnetic design for easy attachment to clothes, ensuring it's always ready for instant use.	OLED Touchscreen The receiver has a built-in 0.95-inch OLED touchscreen that provides intuitive access to different operations.

14-Hour Recording

With 8 GB of internal storage, record up to 14 hours of compressionless 48kHz 24-bit audio and output files quickly to a computer via data cable.

Vastly Compatible

Different devices mean different input adapters, and DJI Mic covers them all. The receiver has USB-C, Lightning, and 3.5mm TRS ports, making it compatible with mainstream smartphones, cameras, and laptops.

Safety Track Effectively suppresses wind and noisy environments while still recording clear sound.	Multi-level Gain Control Adjust input and output sensitivity between -12dB ~ 12dB and find the perfect setting for your surrounding.	Microphone Windscreen Effectively suppresses wind and noisy environments while still recording clear sound.



DJI Mic Specs

Category	DJI Mic Transmitter (AST01)	DJI Mic Receiver (ASR01)	Charging Case (ASB01)
Dimensions	47.32 × 30.43 × 20.01 mm	47.44 × 32.21 × 17.35 mm	103.06 × 61.87 × 41.50 mm
Weight	30 g	24.9 g	162.2 g
Wireless Mode	GFSK 1 Mbps & 2 Mbps	GFSK 1 Mbps & 2 Mbps	–
EIRP (Power)	< 20 dBm	< 20 dBm	–
Operating Frequency	2400–2483.5 MHz	2400–2483.5 MHz	–
Battery Type	LiPo 1S	LiPo 1S	LiPo 1S
Battery Capacity	320 mAh	320 mAh	2600 mAh
Battery Energy	1.23 Wh	1.23 Wh	10 Wh
Battery Voltage	3.85 V	3.85 V	3.87 V
Charging Spec	Max 5 V	Max 5 V	Max 5 V, 3.5 A
Charging Temp	5–45 °C (41–113 °F)	5–45 °C (41–113 °F)	5–45 °C (41–113 °F)
Operating Temp	-10–45 °C (14–113 °F)	-10–45 °C (14–113 °F)	5–45 °C (41–113 °F)
Charging Time	70 mins	70 mins	2h 40m
Operating Time	5.5 hours	5 hours	Fully charges 3 devices ×1.8
Special Feature	–	–	Charges transmitter & receiver



General Specs

Feature	Spec
Microphone Directions	Omnidirectional
Frequency Response	Low Cut Off: 50 Hz–20 kHz Low Cut On: 150 Hz–20 kHz
Max Sound Pressure Level (SPL)	114 dB SPL
Max Input Level (3.5 mm)	-17 dBV (THD < 0.1%)
Equivalent Noise	23 dBA
Monitor Interface Output Power	Max 22 mW @ 1 kHz, 32Ω
Max Transmission Distance	250 m (FCC) 160 m (CE)
Test Environment	Outdoor, unobstructed, interference-free
